Shougang high-strength non-oriented electrical steel

Shougang High-Strength Non-Oriented Electrical Steel 25Swys500 35Swys500 35Swys600 35Swys900 50Swys650 65Swys600

Series grades

0.25mm

25SWYS500

0.35mm

35SWYS500 / 35SWYS600 / 35SWYS900

0.50mm

50SWYS650

0.65mm

65SWYS600
Shougang High-Strength Non-Oriented Electrical Steel 25Swys500 35Swys500 35Swys600 35Swys900 50Swys650 65Swys600

Feature

Application

New energy vehicle high-speed drive motor rotor.

Product advantages

The yield strength reaches 950MPa, which is 150MPa higher than the highest yield strength of electrical steel in the world.

Application effect

By using Shougang 35SWYS900 non-oriented electrical steel products, the motor torque increased by 11.3% and the maximum efficiency point increased by 0.7%.

Magnetic Properties and Mechanical Properties

Grades Core loss
P1.0/400(W/kg)
Magnetic induction
B50(T)
Hardness
(HV1)
Yield strength
(MPa)
Tensile strength
(MPa)
35SWYS600 38.0 1.63 235 615 685
35SWYS900 60.0 1.54 300 940 960
Shougang High-Strength Non-Oriented Electrical Steel 25Swys500 35Swys500 35Swys600 35Swys900 50Swys650 65Swys600
Shougang High-Strength Non-Oriented Electrical Steel 25Swys500 35Swys500 35Swys600 35Swys900 50Swys650 65Swys600

Silicon steel materials in stock

Shougang High-Strength Non-Oriented Electrical Steel 25Swys500 35Swys500 35Swys600 35Swys900 50Swys650 65Swys600

Spot wholesale and retail

Manufacturing Rotor and Stator Stacks Core
